LED Puff Linear
AXUL820
Ideal for apartments, motels, and condos. Perfect for kitchens, utility, closets, schools, garages, and offices. You see the light, not the fixture.
Model data
| Part | Wattage | Lumens | CRI | Dimensions |
|---|---|---|---|---|
| AXUL820 | 36W (2x 18W) | 3,000lm | 80 | 4.75”W x 2”H x 23.5”L |
Specifications
| UL or ETL Listing | Damp Locations |
|---|---|
| Housing | Die formed heavy gauge steel |
| Ends | Design embossed ends are locked and secured to the housing |
| Lens/Diffuser | Dur-illume 2200™ Co-polyester. Indestructible lens. |
| Voltage | 120v - 277v |
| Light Source | 2x LED T8 Tube (sold separately) |
| CRI | >80 |
| Kelvin | 30K, 40K, 50K |
| EM Back-up | 90 minute minimum operation |
| Mounting | Ceiling. Suitable for individual or continuous run installations. May be surface mounted or suspended on stems/rods. |
| Suggested lamps | LEDT801 • 30K • 80 CRI / LEDT804 • 40K • 80 CRI / LEDT805 • 50K • 80 CRI |
Options and ordering
Wattage
- 36W = 2x 18W LED T8 Tubes
Kelvin/CCT
- 30K = 3000˚Kelvin
- 40K = 4000˚Kelvin
- 50K = 5000˚Kelvin
Finish
- WH = White
Options
- EM = Emergency Back-up
Ordering example
AXUL820-36W-30K-WH-EM
