LED Color/Kelvin Selectable Under Cabinet Light
AXUL8AXUL12AXUL18AXUL21AXUL24AXUL33AXUL42
Self contained task light for under cabinets, work stations, over cabinet accent light, display cases and exhibits, merchandising, indirect accent, wall units, and bars.
Model data
| Part | Wattage | Lumens | Kelvin | Length |
|---|---|---|---|---|
| AXUL8 | 4w | 350lm | 30K, 40K | 8” |
| AXUL12 | 7.5w | 560lm | 30K, 40K | 12” |
| AXUL18 | 6.5w | 500lm | 30K, 40K | 18” |
| AXUL21 | 6.8w | 600lm | 30K, 40K | 21” |
| AXUL24 | 7.8w | 680lm | 30K, 40K | 24” |
| AXUL33 | 10.75w | 850lm | 30K, 40K | 33” |
| AXUL42 | 13.45w | 1150lm | 30K, 40K | 42” |
Specifications
| UL or ETL Listing | CE, UL, cUL listed |
|---|---|
| Housing | Heavy Duty Steel |
| Lens/Diffuser | Injection molded white ribbed acrylic |
| Voltage | AC 120v |
| Light Source | Integrated LED |
| CRI | >80 |
| Kelvin | Color/Kelvin Selectable Fixture 30k & 40k |
| Mounting | Hardwire connections for ceiling or wall. Suitable for non-insulated surfaces. Side and rear knock-outs. Linkable design for multiple units. |
| Features | Easy access on/off switch, side and rear knock-outs. |
Options and ordering
Ordering prefix
- AXUL8-4W
- AXUL12-7.5W
- AXUL18-6.5W
- AXUL21-6.8W
- AXUL24-7.8W
- AXUL33-10.75W
- AXUL42-13.45W
Kelvin/CCT
- CCT = Selectable CCT (30K, 40K)
Finish
- WH = White
Ordering example
AXUL12-7.5W-CCT-WH
