Medium/Large Wall Pack
AXWP916-45WAXWP916-70WAXWP935-90WAXWP935-135W
Ideal for entrances, parking areas, building perimeter, walkways, underpasses, loading docks, recreation areas, and more.
Model data
| Part | Wattage | Lumens | Kelvin | CRI | Dimensions |
|---|---|---|---|---|---|
| AXWP916-45W | 45w | 5,200lm | 50K | >75 | 9.2”H x 14.2”W x 7.4” Ext. |
| AXWP916-70W | 70w | 8,000lm | 50K | >75 | 9.2”H x 14.2”W x 7.4” Ext. |
| AXWP935-90W | 90w | 10,900lm | 50K | 80 | 9.75”H x 18”W x 8.75” Ext. |
| AXWP935-135W | 135w | 15,600lm | 50K | 80 | 9.75”H x 18”W x 8.75” Ext. |
Specifications
| UL or ETL Listing | Wet Locations (IP65). Approved UL1598 |
|---|---|
| DLC | 4.1 listed. DLC Premium |
| Housing | Heavy Duty Die Cast Aluminum |
| Photo-control | Optional, easy field install |
| Lens/Diffuser | Tempered glass diffuser. Dust-proof, insect, heat, and impact resistant |
| Voltage | 120v-277v |
| Light Source | Integrated LED Type III |
| CRI | >Ra-75+ |
| Kelvin | 30K, 40K, 50K |
| Ambient Temp. | Suitable for 40˚ temperatures |
| Cold Weather | Cold weather starting -40˚C to +54˚C (-40˚F to +130˚F) |
| EM Back-Up | 90 minutes minimum operation |
| Mounting | Mounts directly to standard 4” J box or directly to wall |
Options and ordering
Kelvin/CCT
- 30K = 3000˚Kelvin
- 40K = 4000˚Kelvin
- 50K = 5000˚Kelvin
Finish
- DB = Dark Bronze
Options
- AT120 = Photocontrol (120-277vac)
- EM = Emergency Back-up
Ordering example
AXWP916-45W-50KDB--AT120
