LED Designer Post Top
AXPT4190AXPT4190-24WAXPT4190-35WAXPT4190-45W
Classic design, the product is simple, modern, and elegant. This elegant design will fit the aesthetic of both modern and traditional buildings. Ideal for single and multi-family communities and commercial installations, motels, and hotels. Perfect for landscape, entrances, perimeter, and pool applications.
Model numbers
| Model | Description |
|---|---|
| AXPT4190 | Ordering prefix |
| AXPT4190-24W | Wattage 35W; Lumens 3,960lm; CRI 80; Energy Savings =150w PSMH |
| AXPT4190-35W | Wattage 45W; Lumens 4,950lm; CRI 80; Energy Savings =175w PSMH |
| AXPT4190-45W | Wattage 54W; Lumens 5,940lm; CRI 80; Energy Savings =250w PSMH |
Specifications
| Body | Die cast aluminum |
|---|---|
| Optical | Anodized PP Plastic Reflector |
| Lens | Tempered Glass |
| Gear Plate | Galvanized steel plate |
| Light Source | E26 medium base |
| Mounting | Fits 3” OD pole |
| UL Listing | Wet Location IP65 |
| Cold Weather Start | - 35˚C to +55˚C (-31˚F to +131˚F) |
| Dimensions | 42”H x 18”W |
| Light Distribution | Type 5: The Type 5 distribution is ideal for general parking and area lighting applications. Intended to be located at or near the center of an intersection or in a large area since it has no beams, but produces a circular distribution with essentially the same candlepower at all lateral angles. |
| Recommended Lamp | CORN-360: 35W - 50K; 45W - 50K; 54W - 50K |
Options and ordering
Wattage
- 30W
Voltage
- U = 120-277V
Kelvin/CCT
- 50K = 5000˚Kelvin
Finish
- BK = Black
Ordering example
AXPT4190-30W-U-50K-BK
