LED Designer Post Top
AXPT4130AXPT4130-35WAXPT4130-45WAXPT4130-54W
Classic design, the product is simple, modern, and elegant. This elegant design will fit the aesthetic of both modern and traditional buildings. Ideal for single and multi-family communities and commercial installations, motels, and hotels. Perfect for landscape, entrances, perimeter, and pool applications.
Model numbers
| Model | Description |
|---|---|
| AXPT4130 | Ordering prefix |
| AXPT4130-35W | Wattage 35W; Base E26; Lumens 3,960lm; CRI 80; Energy Savings =150w PSMH |
| AXPT4130-45W | Wattage 45W; Base E26; Lumens 4,950lm; CRI 80; Energy Savings =175w PSMH |
| AXPT4130-54W | Wattage 54W; Base E26; Lumens 5,940lm; CRI 80; Energy Savings =250w PSMH |
Specifications
| Canopy | Aluminum |
|---|---|
| Support Staffs | Fiberglass reinforced plastics. Excellent mechanical strength. |
| Reflector | High Grade Aluminum |
| UL Listing | Wet Location IP65 |
| Socket | 1x E26 Medium Base |
| Lamp | LED Corn (sold separately) |
| Mounting | Fits 3” OD pole |
| Dimensions | 29”H x 25”W |
| Light Distribution | Type 5: The Type 5 distribution is ideal for general parking and area lighting applications. Intended to be located at or near the center of an intersection or in a large area since it has no beams, but produces a circular distribution with essentially the same candlepower at all lateral angles. |
| Recommended Lamp | CORN-360: 35W - 50K; 45W - 50K; 54W - 50K |
Options and ordering
Wattage
- 35W
- 45W
- 54W
Voltage
- U = 120-277V
Kelvin/CCT
- 50K = 5000˚Kelvin
Finish
- DG = Dark Grey
Ordering example
AXPT4130-35W-U-50K-DG
