LED Exit and Emergency

Thermoplastic LED Emergency Unit

AXE3051

  • UL

Model numbers

ModelDescription
AXE3051Thermoplastic LED Emergency Unit

Specifications

VoltageDual 120/277
Charge Rate / Power“ON” LED indicator light and push-to-test switch for mandated code compliance.
Battery3.6v long-life, maintenance free, rechargeable Ni-MH battery.
Transfer SwitchInternal solid state. Automatically connects the internal battery to LED board and lamp heads for minimum 90min. emergency illumination.
ChargerFully automatic, solid state, two rate charger initiates battery charging to recharge a discharged battery in 24 hrs.
MountingUniversal J-Box mounting pattern.

Options and ordering

Housing Color

  • BK = Black
  • WH = White

Options

  • RC = Remote Capable

Ordering example

AXE3051-WH-RC
