Thermoplastic LED Exit/Emergency Combo
AXE1003
Model numbers
| Model | Description |
|---|---|
| AXE1003 | Thermoplastic LED Exit/Emergency Combo |
Specifications
| Voltage | Dual 120/277 |
|---|---|
| Charge Rate / Power | “ON” LED indicator light and push-to-test switch for mandated code compliance. |
| Battery | 9.6v maintenance free, rechargeable NiCd battery. (EM Standard) |
| Transfer Switch | Internal solid state. Automatically connects the internal battery to LED board and lamp heads for minimum 90min. emergency illumination. |
| Charger | Fully automatic, solid state, two rate charger initiates battery charging to recharge a discharged battery in 24 hrs. |
| Mounting | EZ-snap mounting canopy included for top or end mount. Universal knock-out pattern on backplate for wall mount. |
| Housing | EZ-snap chevron directional indicators. Compact, low-profile design. |
| Construction | Injection molded, engineering grade, 5VA flame retardant, high impact resistant thermoplastic |
| Option SDT | Self diagnosis feature performs monthly, biannual, and annual tests to ensure reliable operation and meet electrical and life safety codes. |
| Option HL | 12-LED heads provide increased center-to-center spacing (1.5w per head). |
| Option NH | No lamp head attached to the unit enabling it to be used as a remote capable exit sign. |
| Option RC | Remote capacity of up to 3.0 watts. |
Options and ordering
# of Faces
- 2 = Universal Single/ Double Face
Letter Color
- R = Red
- G = Green
Housing Color
- WH = White
- BK = Black
Battery
- Blank = Battery Back-up
- AC = AC Only
Options
- SDT = Self-Diagnostics (EM units only)
- RC = Remote Capacity
- HL = High Lumen
- NH = No Lamp Heads
Ordering example
AXE1003-2-R-WH-AC-SDT
