Commercial Grade LED String Lights

AXSTL830

Ideal for patios, overhangs, outdoor living areas, tents for weddings or festivals, and event lighting. Hanging Instructions: Light sockets must be suspended so that bulbs are facing down only. DO NOT MOUNT THE LIGHT STRINGS WITH SOCKETS FACING UPWARD!
Light string must be securely attached to a support structure at each end of each span. The maximum unsupported span distance for 48 foot Cord & Plug Light String is 20 feet (10 sockets).
Secure light string to supporting hardware (eye bolts, brackets, etc - not included) using cable ties (not included).
Ensure any cut ends are properly sealed to prevent entrance of water
For spans exceeding 20 feet, use properly rated cable support system and cable ties (neither are provided with light string) and follow local codes for suspended cables and loads.
See accessories on the following page.

Model numbers

Model	Description
AXSTL830	Commercial Grade LED String Lights

ETL Listing	Indoor/Outdoor. Suitable for year-round use. IP64
Wire Color	Black
Wire Type	2-wire with 120V plug and terminated end.
Sockets	48’ = 24 Sockets; 100’ = 50 Sockets
Light Source	E26 Medium Base - S14 Bulb
Voltage	120V
Wattage	48’ = 600W per string; 100’ = 1,250W per string
Socket Spacing	24”
Construction	Formulated PVC sockets form a tight seal around bulbs to preclude the entrance of water and moisture. Suspended socket has T-mold with mounting hole at top while non- suspended socket has two mounting ears built into the base.
Mounting	For spans up to 20 feet, use eye bolts and plastic ties to anchor ends. For spans longer than 20 feet, use catenary cable (sold separately) with plastic ties at each socket.
Cord & Plug Set	Lead wire (16”L); Tail wire (9”L)

AXSTL830-48-S-BK
