LED Flood Light
AXFLFL750-45WAXFL750-70WEP902SMB
- Ideal for building facade lighting, sports fields, landscape lighting, uplighting for signs/displays, and many other general applications where flood lighting may be useful.
- Knuckle Mount (included)
- EP902SMB Small Mounting Yoke
- PS Pole Slip-fitter
Model numbers
| Model | Description |
|---|---|
| EP902SMB | Small Mounting Yoke (option). EP902SMB = Small Mounting Yoke |
Model data
| Part | Wattage | Lumens | CRI | Dimensions |
|---|---|---|---|---|
| AXFLFL750-45W | 45W | 4,950lm | 80 | 4.33”H x 8.67”W x 5”Ext. |
| AXFL750-70W | 70W | 6,800lm | 80 | 4.33”H x 8.67”W x 5”Ext. |
Specifications
| UL or ETL Listing | Suitable for Wet Locations and Ground Mounting |
|---|---|
| DLC | Listed |
| Housing | Heavy duty die-cast aluminum |
| LED Chip | Phillips rated 50,000 hr. |
| Voltage | 120v - 277v |
| LED Driver | High Lumen Output |
| Kelvin | 50K standard |
| Ambient Temp. | Suitable for 40˚C temperatures. |
| Cold Weather | Cold Weather Starting -40˚C (-40˚F) |
| Mounting | Knuckle, Trunnion, or Slip-fitter |
| Photocontrol | Sold Separately, Easy Field Install |
Options and ordering
Ordering prefix
- AXFL750
Wattage
- 45W = 45 watt Integrated LED
- 70W = 70 watt Integrated LED
Kelvin/CCT
- 50K = 5000˚ Kelvin
Finish
- DB = Dark Bronze
Options
- AT120 = Photocontrol (120-277vac)
- EP902SMB = Small Mounting Yoke
- PS = Pole Slip Fitter
Ordering example
AXFL750-45W-50K-ASM
