8” Disk w/ Emergency Back-Up
AXEM628
- Replaces 6” Recessed Can Light - Retrofit Kit Available
- Replaces 8” Recessed Can Light - Retrofit Kit Available
- LED flush mounts add class to any decor. Low profile design ideally suited for showers, lobbies, corridors, conference rooms, common spaces, kitchenettes, and interiors in commercial, hospitality, retail, and residential environments.
Model numbers
| Model | Description |
|---|---|
| AXEM628 | 8” Disk w/ Emergency Back-Up |
Specifications
| UL or ETL Listing | Wet Locations |
|---|---|
| Certifications | Title 24, JA8 Certified DLC Certified |
| Dimensions | 1.2” Height x 8.5” Outside Diameter |
| Housing | Stamped Steel |
| Lens/Diffuser | UV Rated Polycarbonate |
| Voltage | AC 110-120v - Driverless |
| Wattage | 20w (EM: 8w) |
| Lumens | 1,400lm (EM: 560lm) |
| CRI | 80 |
| Kelvin | 30K, 40K |
| Emergency Mode | Up to 90 Minutes |
| Flicker | (T24, JA8) Flicker Free |
| Dimmable | No |
| Operating Temp. | (-20˚ to -40˚C) (25˚C Nominal) |
| Surge Protection | 1 kv |
| Mounting | Ceiling, includes all necessary hardware. Mounts to most 4” x 4” J boxes. Suitable for installation within closets and/or storage spaces per NEC code 410.16. |
Options and ordering
Wattage
- 20W = 20 Watts
Kelvin/CCT
- 30K = 3000˚K
- 40K = 4000˚K
Finish
- BN = Brushed Nickel
- ORB = Oil Rubbed Bronze
- WH = White
Options
- AX888 = Retrofit Kit
Ordering example
AXEM628-20W-30K-WH
